How to secure OpenSearch cluster using TLS certificates

Here in this article we will try to configure OpenSearch cluster using TLS certificates to secure the REST API and Transport layer communications.

Table of Contents

Test Environment

Fedora 41 server
Docker version 27.4.1
Docker Compose v2.32.1

Encryption in Transit

OpenSearch Security is responsible to managing encryption in transit. The encryption in transit covers two important aspects of communication.

REST Layer: This is the communication that takes place between client and OpenSerach cluster node
TLS Layer: This is the communication that takes place between OpenSearch cluster nodes

OpenSearch uses the TLS protocol for encryption of both these channels. This ensures that both requests to OpenSearch and the movement of data among different nodes are safe and secure from tampering.

If you are interested in watching the video. Here is the YouTube video on the same step by step procedure outlined below.

Procedure

Step1: Generate REST and TLS Layer certificates

Here we will be generating the following public private certificate key pairs by running the “cert_generate.sh ” script.

Root CA cert keypair
admin user client certificate issued by the Root CA
Node cert keypair issued by the Root CA
OpenSearch Dashboard cert keypair

admin@linuxser:~/opensearch$ cat cert_generate.sh
#!/bin/sh
# Root CA
openssl genrsa -out root-ca-key.pem 2048
openssl req -new -x509 -sha256 -key root-ca-key.pem -subj "/C=IN/ST=MH/L=Mumbai/O=stack/OU=middleware/CN=linuxser.stack.com" -out root-ca.pem -days 730

# Admin cert
openssl genrsa -out kirk-key-temp.pem 2048
openssl pkcs8 -inform PEM -outform PEM -in kirk-key-temp.pem -topk8 -nocrypt -v1 PBE-SHA1-3DES -out kirk-key.pem
openssl req -new -key kirk-key.pem -subj "/C=IN/ST=MH/L=Mumbai/O=stack/OU=middleware/CN=kirk" -out kirk.csr
openssl x509 -req -in kirk.csr -CA root-ca.pem -CAkey root-ca-key.pem -CAcreateserial -sha256 -out kirk.pem -days 730

# Node cert
openssl genrsa -out esnode-key-temp.pem 2048
openssl pkcs8 -inform PEM -outform PEM -in esnode-key-temp.pem -topk8 -nocrypt -v1 PBE-SHA1-3DES -out esnode-key.pem
openssl req -new -key esnode-key.pem -subj "/C=IN/ST=MH/L=Mumbai/O=stack/OU=middleware/CN=opensearch-node.stack.com" -out esnode.csr
echo 'subjectAltName=DNS:opensearch-node.stack.com' > esnode.ext
openssl x509 -req -in esnode.csr -CA root-ca.pem -CAkey root-ca-key.pem -CAcreateserial -sha256 -out esnode.pem -days 730 -extfile esnode.ext

# OpenSearch Dashboard cert
openssl req -x509 -newkey rsa:2048 -nodes -keyout opensearch_dashboards.key -out opensearch_dashboards.crt -days 365 -subj "/C=IN/ST=MH/L=Mumbai/O=stack/OU=middleware/CN=linuxser.stack.com"

# Cleanup
rm kirk-key-temp.pem
rm kirk.csr
rm esnode-key-temp.pem
rm esnode.csr
rm esnode.ext

admin@linuxser:~/opensearch$ ./cert_generate.sh

Here is the list of certificate keypair that are generated.

-rw-------. 1 admin admin  1704 Oct 25 23:28 root-ca-key.pem
-rw-r--r--. 1 admin admin  1354 Oct 25 23:28 root-ca.pem
-rw-------. 1 admin admin  1704 Oct 25 23:28 kirk-key.pem
-rw-r--r--. 1 admin admin  1314 Oct 25 23:28 kirk.pem
-rw-------. 1 admin admin  1704 Oct 25 23:28 esnode-key.pem
-rw-r--r--. 1 admin admin    41 Oct 25 23:28 root-ca.srl
-rw-r--r--. 1 admin admin  1395 Oct 25 23:28 esnode.pem
-rw-------. 1 admin admin  1704 Oct 25 23:28 opensearch_dashboards.key
-rw-r--r--. 1 admin admin  1354 Oct 25 23:28 opensearch_dashboards.crt

Step2: Configure OpenSearch

We need to configure the OpenSearch security configuration file “opensearch.yml” which contains paths to TLS certificates and their attributes, such as distinguished names and trusted certificate authorities as shown below.

admin@linuxser:~/opensearch$ cat opensearch.yml
---
cluster.name: docker-cluster

# Bind to all interfaces because we don't know what IP address Docker will assign to us.
network.host: 0.0.0.0

# # minimum_master_nodes need to be explicitly set when bound on a public IP
# # set to 1 to allow single node clusters
# discovery.zen.minimum_master_nodes: 1

# Setting network.host to a non-loopback address enables the annoying bootstrap checks. "Single-node" mode disables them again.
# discovery.type: single-node


######## Start OpenSearch Security Demo Configuration ########
# WARNING: revise all the lines below before you go into production
plugins.security.ssl.transport.pemcert_filepath: esnode.pem
plugins.security.ssl.transport.pemkey_filepath: esnode-key.pem
plugins.security.ssl.transport.pemtrustedcas_filepath: root-ca.pem
plugins.security.ssl.transport.enforce_hostname_verification: false
plugins.security.ssl.http.enabled: true
plugins.security.ssl.http.pemcert_filepath: esnode.pem
plugins.security.ssl.http.pemkey_filepath: esnode-key.pem
plugins.security.ssl.http.pemtrustedcas_filepath: root-ca.pem
plugins.security.allow_unsafe_democertificates: false
plugins.security.nodes_dn:
  - 'CN=*.stack.com,OU=middleware,O=stack,L=Mumbai,ST=MH,C=IN'
plugins.security.allow_default_init_securityindex: true
plugins.security.authcz.admin_dn: ['CN=kirk,OU=middleware,O=stack,L=Mumbai,ST=MH,C=IN']
plugins.security.audit.type: internal_opensearch
plugins.security.enable_snapshot_restore_privilege: true
plugins.security.check_snapshot_restore_write_privileges: true
plugins.security.restapi.roles_enabled: [all_access, security_rest_api_access]
plugins.security.system_indices.enabled: true
plugins.security.system_indices.indices: [.plugins-ml-agent, .plugins-ml-config, .plugins-ml-connector,
  .plugins-ml-controller, .plugins-ml-model-group, .plugins-ml-model, .plugins-ml-task,
  .plugins-ml-conversation-meta, .plugins-ml-conversation-interactions, .plugins-ml-memory-meta,
  .plugins-ml-memory-message, .plugins-ml-stop-words, .opendistro-alerting-config,
  .opendistro-alerting-alert*, .opendistro-anomaly-results*, .opendistro-anomaly-detector*,
  .opendistro-anomaly-checkpoints, .opendistro-anomaly-detection-state, .opendistro-reports-*,
  .opensearch-notifications-*, .opensearch-notebooks, .opensearch-observability, .ql-datasources,
  .opendistro-asynchronous-search-response*, .replication-metadata-store, .opensearch-knn-models,
  .geospatial-ip2geo-data*, .plugins-flow-framework-config, .plugins-flow-framework-templates,
  .plugins-flow-framework-state, .plugins-search-relevance-experiment, .plugins-search-relevance-judgment-cache]
node.max_local_storage_nodes: 3
######## End OpenSearch Security Demo Configuration ########

Step3: Configure Authentication Backend

Here we will configure the OpenSearch security config.yml with the internal user database authentication backend. As you can see from the configuration we have “authc” with “basic_internal_auth_domain” enabled for the same.

admin@linuxser:~/opensearch$ cat config.yml
---

# This is the main OpenSearch Security configuration file where authentication
# and authorization is defined.
#
# You need to configure at least one authentication domain in the authc of this file.
# An authentication domain is responsible for extracting the user credentials from
# the request and for validating them against an authentication backend like Active Directory for example.
#
# If more than one authentication domain is configured the first one which succeeds wins.
# If all authentication domains fail then the request is unauthenticated.
# In this case an exception is thrown and/or the HTTP status is set to 401.
#
# After authentication authorization (authz) will be applied. There can be zero or more authorizers which collect
# the roles from a given backend for the authenticated user.
#
# Both, authc and auth can be enabled/disabled separately for REST and TRANSPORT layer. Default is true for both.
#        http_enabled: true
#        transport_enabled: true
#
# For HTTP it is possible to allow anonymous authentication. If that is the case then the HTTP authenticators try to
# find user credentials in the HTTP request. If credentials are found then the user gets regularly authenticated.
# If none can be found the user will be authenticated as an "anonymous" user. This user has always the username "anonymous"
# and one role named "anonymous_backendrole".
# If you enable anonymous authentication all HTTP authenticators will not challenge.
#
#
# Note: If you define more than one HTTP authenticators make sure to put non-challenging authenticators like "proxy" or "clientcert"
# first and the challenging one last.
# Because it's not possible to challenge a client with two different authentication methods (for example
# Kerberos and Basic) only one can have the challenge flag set to true. You can cope with this situation
# by using pre-authentication, e.g. sending a HTTP Basic authentication header in the request.
#
# Default value of the challenge flag is true.
#
#
# HTTP
#   basic (challenging)
#   proxy (not challenging, needs xff)
#   kerberos (challenging)
#   clientcert (not challenging, needs https)
#   jwt (not challenging)
#   host (not challenging) #DEPRECATED, will be removed in a future version.
#                          host based authentication is configurable in roles_mapping

# Authc
#   internal
#   noop
#   ldap

# Authz
#   ldap
#   noop



_meta:
  type: "config"
  config_version: 2

config:
  dynamic:
    # Set filtered_alias_mode to 'disallow' to forbid more than 2 filtered aliases per index
    # Set filtered_alias_mode to 'warn' to allow more than 2 filtered aliases per index but warns about it (default)
    # Set filtered_alias_mode to 'nowarn' to allow more than 2 filtered aliases per index silently
    #filtered_alias_mode: warn
    #do_not_fail_on_forbidden: false
    #kibana:
    # Kibana multitenancy
    #multitenancy_enabled: true
    #private_tenant_enabled: true
    #default_tenant: ""
    #server_username: kibanaserver
    #index: '.kibana'
    http:
      anonymous_auth_enabled: false
      xff:
        enabled: false
        internalProxies: '192\.168\.0\.10|192\.168\.0\.11' # regex pattern
        #internalProxies: '.*' # trust all internal proxies, regex pattern
        #remoteIpHeader:  'x-forwarded-for'
        ###### see https://docs.oracle.com/javase/7/docs/api/java/util/regex/Pattern.html for regex help
        ###### more information about XFF https://en.wikipedia.org/wiki/X-Forwarded-For
        ###### and here https://tools.ietf.org/html/rfc7239
        ###### and https://tomcat.apache.org/tomcat-8.0-doc/config/valve.html#Remote_IP_Valve
    authc:
      kerberos_auth_domain:
        http_enabled: false
        transport_enabled: false
        order: 6
        http_authenticator:
          type: kerberos
          challenge: true
          config:
            # If true a lot of kerberos/security related debugging output will be logged to standard out
            krb_debug: false
            # If true then the realm will be stripped from the user name
            strip_realm_from_principal: true
        authentication_backend:
          type: noop
      basic_internal_auth_domain:
        description: "Authenticate via HTTP Basic against internal users database"
        http_enabled: true
        transport_enabled: true
        order: 4
        http_authenticator:
          type: basic
          challenge: true
        authentication_backend:
          type: intern
      proxy_auth_domain:
        description: "Authenticate via proxy"
        http_enabled: false
        transport_enabled: false
        order: 3
        http_authenticator:
          type: proxy
          challenge: false
          config:
            user_header: "x-proxy-user"
            roles_header: "x-proxy-roles"
        authentication_backend:
          type: noop
      jwt_auth_domain:
        description: "Authenticate via Json Web Token"
        http_enabled: false
        transport_enabled: false
        order: 0
        http_authenticator:
          type: jwt
          challenge: false
          config:
            jwks_uri: 'https://your-jwks-endpoint.com/.well-known/jwks.json'
            signing_key: "base64 encoded HMAC key or public RSA/ECDSA pem key"
            jwt_header: "Authorization"
            jwt_url_parameter: null
            jwt_clock_skew_tolerance_seconds: 30
            roles_key: null
            subject_key: null
        authentication_backend:
          type: noop
      clientcert_auth_domain:
        description: "Authenticate via SSL client certificates"
        http_enabled: false
        transport_enabled: false
        order: 2
        http_authenticator:
          type: clientcert
          config:
            username_attribute: cn #optional, if omitted DN becomes username
            # skip_users config is used to skip cert based authentication for certain users where they can fall back to other authentication backends
            #skip_users:
            #  - "DC=de,L=test,O=users,OU=bridge,CN=dashboard"

          challenge: false
        authentication_backend:
          type: noop
      ldap:
        description: "Authenticate via LDAP or Active Directory"
        http_enabled: false
        transport_enabled: false
        order: 5
        http_authenticator:
          type: basic
          challenge: false
        authentication_backend:
          # LDAP authentication backend (authenticate users against a LDAP or Active Directory)
          type: ldap
          config:
            # enable ldaps
            enable_ssl: false
            # enable start tls, enable_ssl should be false
            enable_start_tls: false
            # send client certificate
            enable_ssl_client_auth: false
            # verify ldap hostname
            verify_hostnames: true
            hosts:
            - localhost:8389
            bind_dn: null
            password: null
            userbase: 'ou=people,dc=example,dc=com'
            # Filter to search for users (currently in the whole subtree beneath userbase)
            # {0} is substituted with the username
            usersearch: '(sAMAccountName={0})'
            # Use this attribute from the user as username (if not set then DN is used)
            username_attribute: null
    authz:
      roles_from_myldap:
        description: "Authorize via LDAP or Active Directory"
        http_enabled: false
        transport_enabled: false
        authorization_backend:
          # LDAP authorization backend (gather roles from a LDAP or Active Directory, you have to configure the above LDAP authentication backend settings too)
          type: ldap
          config:
            # enable ldaps
            enable_ssl: false
            # enable start tls, enable_ssl should be false
            enable_start_tls: false
            # send client certificate
            enable_ssl_client_auth: false
            # verify ldap hostname
            verify_hostnames: true
            hosts:
            - localhost:8389
            bind_dn: null
            password: null
            rolebase: 'ou=groups,dc=example,dc=com'
            # Filter to search for roles (currently in the whole subtree beneath rolebase)
            # {0} is substituted with the DN of the user
            # {1} is substituted with the username
            # {2} is substituted with an attribute value from user's directory entry, of the authenticated user. Use userroleattribute to specify the name of the attribute
            rolesearch: '(member={0})'
            # Specify the name of the attribute which value should be substituted with {2} above
            userroleattribute: null
            # Roles as an attribute of the user entry
            userrolename: disabled
            #userrolename: memberOf
            # The attribute in a role entry containing the name of that role, Default is "name".
            # Can also be "dn" to use the full DN as rolename.
            rolename: cn
            # Resolve nested roles transitive (roles which are members of other roles and so on ...)
            resolve_nested_roles: true
            userbase: 'ou=people,dc=example,dc=com'
            # Filter to search for users (currently in the whole subtree beneath userbase)
            # {0} is substituted with the username
            usersearch: '(uid={0})'
            # Skip users matching a user name, a wildcard or a regex pattern
            #skip_users:
            #  - 'cn=Michael Jackson,ou*people,o=TEST'
            #  - '/\S*/'
      roles_from_another_ldap:
        description: "Authorize via another Active Directory"
        http_enabled: false
        transport_enabled: false
        authorization_backend:
          type: ldap
          #config goes here ...
  #    auth_failure_listeners:
  #      ip_rate_limiting:
  #        type: ip
  #        allowed_tries: 10
  #        time_window_seconds: 3600
  #        block_expiry_seconds: 600
  #        max_blocked_clients: 100000
  #        max_tracked_clients: 100000
  #      internal_authentication_backend_limiting:
  #        type: username
  #        authentication_backend: intern
  #        allowed_tries: 10
  #        time_window_seconds: 3600
  #        block_expiry_seconds: 600
  #        max_blocked_clients: 100000
  #        max_tracked_clients: 100000

Step4: Configure OpenSearch Dashboard

Here will need to update the OpenSearch Dasbhoard configuration file “opensearch_dashboards.yml” to enable SSL settings and update the cert and key path values with the correct path where these files are available.

admin@linuxser:~/opensearch$ cat opensearch_dashboards.yml
---
# Copyright OpenSearch Contributors
# SPDX-License-Identifier: Apache-2.0

# Description:
# Default configuration for OpenSearch Dashboards

# OpenSearch Dashboards is served by a back end server. This setting specifies the port to use.
# server.port: 5601

# Specifies the address to which the OpenSearch Dashboards server will bind. IP addresses and host names are both valid values.
# The default is 'localhost', which usually means remote machines will not be able to connect.
# To allow connections from remote users, set this parameter to a non-loopback address.
# server.host: "localhost"

# Enables you to specify a path to mount OpenSearch Dashboards at if you are running behind a proxy.
# Use the `server.rewriteBasePath` setting to tell OpenSearch Dashboards if it should remove the basePath
# from requests it receives, and to prevent a deprecation warning at startup.
# This setting cannot end in a slash.
# server.basePath: ""

# Specifies whether OpenSearch Dashboards should rewrite requests that are prefixed with
# `server.basePath` or require that they are rewritten by your reverse proxy.
# server.rewriteBasePath: false

# The maximum payload size in bytes for incoming server requests.
# server.maxPayloadBytes: 1048576

# The OpenSearch Dashboards server's name. This is used for display purposes.
# server.name: "your-hostname"

# The URLs of the OpenSearch instances to use for all your queries.
# opensearch.hosts: ["http://localhost:9200"]

# OpenSearch Dashboards uses an index in OpenSearch to store saved searches, visualizations and
# dashboards. OpenSearch Dashboards creates a new index if the index doesn't already exist.
# opensearchDashboards.index: ".opensearch_dashboards"

# The default application to load.
# opensearchDashboards.defaultAppId: "home"

# Setting for an optimized healthcheck that only uses the local OpenSearch node to do Dashboards healthcheck.
# This settings should be used for large clusters or for clusters with ingest heavy nodes.
# It allows Dashboards to only healthcheck using the local OpenSearch node rather than fan out requests across all nodes.
#
# It requires the user to create an OpenSearch node attribute with the same name as the value used in the setting
# This node attribute should assign all nodes of the same cluster an integer value that increments with each new cluster that is spun up
# e.g. in opensearch.yml file you would set the value to a setting using node.attr.cluster_id:
# Should only be enabled if there is a corresponding node attribute created in your OpenSearch config that matches the value here
# opensearch.optimizedHealthcheckId: "cluster_id"

# If your OpenSearch is protected with basic authentication, these settings provide
# the username and password that the OpenSearch Dashboards server uses to perform maintenance on the OpenSearch Dashboards
# index at startup. Your OpenSearch Dashboards users still need to authenticate with OpenSearch, which
# is proxied through the OpenSearch Dashboards server.
# opensearch.username: "opensearch_dashboards_system"
# opensearch.password: "pass"

# Enables SSL and paths to the PEM-format SSL certificate and SSL key files, respectively.
# These settings enable SSL for outgoing requests from the OpenSearch Dashboards server to the browser.
server.ssl.enabled: true
server.ssl.certificate: /usr/share/opensearch-dashboards/config/opensearch_dashboards.crt
server.ssl.key: /usr/share/opensearch-dashboards/config/opensearch_dashboards.key

# Optional settings that provide the paths to the PEM-format SSL certificate and key files.
# These files are used to verify the identity of OpenSearch Dashboards to OpenSearch and are required when
# xpack.security.http.ssl.client_authentication in OpenSearch is set to required.
# opensearch.ssl.certificate: /path/to/your/client.crt
# opensearch.ssl.key: /path/to/your/client.key

# Optional setting that enables you to specify a path to the PEM file for the certificate
# authority for your OpenSearch instance.
# opensearch.ssl.certificateAuthorities: [ "/path/to/your/CA.pem" ]

# To disregard the validity of SSL certificates, change this setting's value to 'none'.
# opensearch.ssl.verificationMode: full

# Time in milliseconds to wait for OpenSearch to respond to pings. Defaults to the value of
# the opensearch.requestTimeout setting.
# opensearch.pingTimeout: 1500

# Time in milliseconds to wait for responses from the back end or OpenSearch. This value
# must be a positive integer.
# opensearch.requestTimeout: 30000

# List of OpenSearch Dashboards client-side headers to send to OpenSearch. To send *no* client-side
# headers, set this value to [] (an empty list).
# opensearch.requestHeadersWhitelist: [ authorization ]

# Header names and values that are sent to OpenSearch. Any custom headers cannot be overwritten
# by client-side headers, regardless of the opensearch.requestHeadersWhitelist configuration.
# opensearch.customHeaders: {}

# Time in milliseconds for OpenSearch to wait for responses from shards. Set to 0 to disable.
# opensearch.shardTimeout: 30000

# Logs queries sent to OpenSearch. Requires logging.verbose set to true.
# opensearch.logQueries: false

# Specifies the path where OpenSearch Dashboards creates the process ID file.
# pid.file: /var/run/opensearchDashboards.pid

# Enables you to specify a file where OpenSearch Dashboards stores log output.
# logging.dest: stdout

# 2.15 Ignore 'ENOSPC' error for logging stream.
# When set to true, the 'ENOSPC' error message will not cause the OpenSearch Dashboards process to crash. Otherwise,
# the original behavior will be maintained. It is disabled by default.
# logging.ignoreEnospcError: false

# Set the value of this setting to true to suppress all logging output.
# logging.silent: false

# Set the value of this setting to true to suppress all logging output other than error messages.
# logging.quiet: false

# Set the value of this setting to true to log all events, including system usage information
# and all requests.
# logging.verbose: false

# Set the interval in milliseconds to sample system and process performance
# metrics. Minimum is 100ms. Defaults to 5000.
# ops.interval: 5000

# Specifies locale to be used for all localizable strings, dates and number formats.
# Supported languages are the following: English - en , by default , Chinese - zh-CN .
# i18n.locale: "en"

# Set the allowlist to check input graphite Url. Allowlist is the default check list.
# vis_type_timeline.graphiteAllowedUrls: ['https://www.hostedgraphite.com/UID/ACCESS_KEY/graphite']

# Set the blocklist to check input graphite Url. Blocklist is an IP list.
# Below is an example for reference
# vis_type_timeline.graphiteBlockedIPs: [
# //Loopback
# '127.0.0.0/8',
# '::1/128',
# //Link-local Address for IPv6
# 'fe80::/10',
# //Private IP address for IPv4
# '10.0.0.0/8',
# '172.16.0.0/12',
# '192.168.0.0/16',
# //Unique local address (ULA)
# 'fc00::/7',
# //Reserved IP address
# '0.0.0.0/8',
# '100.64.0.0/10',
# '192.0.0.0/24',
# '192.0.2.0/24',
# '198.18.0.0/15',
# '192.88.99.0/24',
# '198.51.100.0/24',
# '203.0.113.0/24',
# '224.0.0.0/4',
# '240.0.0.0/4',
# '255.255.255.255/32',
# '::/128',
# '2001:db8::/32',
# 'ff00::/8',
# ]
# vis_type_timeline.graphiteBlockedIPs: []

# opensearchDashboards.branding:
# logo:
# defaultUrl: ""
# darkModeUrl: ""
# mark:
# defaultUrl: ""
# darkModeUrl: ""
# loadingLogo:
# defaultUrl: ""
# darkModeUrl: ""
# faviconUrl: ""
# applicationTitle: ""

# Set the value of this setting to true to capture region blocked warnings and errors
# for your map rendering services.
# map.showRegionBlockedWarning: false%

# Set the value of this setting to false to suppress search usage telemetry
# for reducing the load of OpenSearch cluster.
# data.search.usageTelemetry.enabled: false

# 2.4 renames 'wizard.enabled: false' to 'vis_builder.enabled: false'
# Set the value of this setting to false to disable VisBuilder
# functionality in Visualization.
# vis_builder.enabled: false

# 2.4 New Experimental Feature
# Set the value of this setting to true to enable the experimental multiple data source
# support feature. Use with caution.
# data_source.enabled: false
# Set the value of these settings to customize crypto materials to encryption saved credentials
# in data sources.
# data_source.encryption.wrappingKeyName: 'changeme'
# data_source.encryption.wrappingKeyNamespace: 'changeme'
# data_source.encryption.wrappingKey: [0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0]

# 2.6 New ML Commons Dashboards Feature
# Set the value of this setting to true to enable the ml commons dashboards
# ml_commons_dashboards.enabled: false

# 2.12 New Experimental Assistant Dashboards Feature
# Set the value of this setting to true to enable the assistant dashboards
# assistant.chat.enabled: false

# 2.13 New Query Assistant Feature
# Set the value of this setting to false to disable the query assistant
# observability.query_assist.enabled: false

# 2.14 Enable Ui Metric Collectors in Usage Collector
# Set the value of this setting to true to enable UI Metric collections
# usageCollection.uiMetric.enabled: false

# 2.18 New Experimental Settings
# Set the value to true to enable
# assistant.alertInsight.enabled: false
# assistant.smartAnomalyDetector.enabled: false
# assistant.text2viz.enabled: false
# queryEnhancements.queryAssist.summary.enabled: false

# 3.3 New Core Settings
# Default to false, set true to not display the explore experience modal
# home.disableWelcomeScreen: false
# home.disableExperienceModal: false

opensearch.hosts: [https://localhost:9200]
opensearch.ssl.verificationMode: none
opensearch.username: kibanaserver
opensearch.password: kibanaserver
opensearch.requestHeadersWhitelist: [authorization, securitytenant]

opensearch_security.multitenancy.enabled: true
opensearch_security.multitenancy.tenants.preferred: [Private, Global]
opensearch_security.readonly_mode.roles: [kibana_read_only]
# Use this setting if you are running opensearch-dashboards without https
opensearch_security.cookie.secure: false
server.host: '0.0.0.0'

Step5: Configure other Security related configuration files

In this step we are going to configure the authentication part of the OpenSearch security to use the internal user database leveraging the roles and role_mapping security related configuration files.

internal_users.yml: This file contains any initial users that you want to add to the Security plugin’s internal user database.
roles_mapping.yml This file enables the assignment of permissions defined in roles.yml to authenticated users or groups from external authentication systems like LDAP or Active Directory.
roles.yml: This file contains predefined roles that grant usage to plugins within the default distribution of OpenSearch.
audit.yml: This file used to define specific settings for the OpenSearch Security plugin’s audit logging feature.

admin@linuxser:~/opensearch$ cat internal_users.yml
---
_meta:
  type: "internalusers"
  config_version: 2
admin:
  hash: "$2y$12$odOCREJBQPx5jq7XKnyRwO7X4W5RhTKo7yc9yNGkiF6DhS2joa.tu"
  reserved: true
  backend_roles:
  - "admin"
  description: "Demo admin user"
anomalyadmin:
  hash: "$2y$12$TRwAAJgnNo67w3rVUz4FIeLx9Dy/llB79zf9I15CKJ9vkM4ZzAd3."
  reserved: false
  opendistro_security_roles:
  - "anomaly_full_access"
  description: "Demo anomaly admin user, using internal role"
kibanaserver:
  hash: "$2a$12$4AcgAt3xwOWadA5s5blL6ev39OXDNhmOesEoo33eZtrq2N0YrU3H."
  reserved: true
  description: "Demo OpenSearch Dashboards user"
kibanaro:
  hash: "$2a$12$JJSXNfTowz7Uu5ttXfeYpeYE0arACvcwlPBStB1F.MI7f0U9Z4DGC"
  reserved: false
  backend_roles:
  - "kibanauser"
  - "readall"
  attributes:
    attribute1: "value1"
    attribute2: "value2"
    attribute3: "value3"
  description: "Demo OpenSearch Dashboards read only user, using external role mapping"
logstash:
  hash: "$2a$12$u1ShR4l4uBS3Uv59Pa2y5.1uQuZBrZtmNfqB3iM/.jL0XoV9sghS2"
  reserved: false
  backend_roles:
  - "logstash"
  description: "Demo logstash user, using external role mapping"
readall:
  hash: "$2a$12$ae4ycwzwvLtZxwZ82RmiEunBbIPiAmGZduBAjKN0TXdwQFtCwARz2"
  reserved: false
  backend_roles:
  - "readall"
  description: "Demo readall user, using external role mapping"
snapshotrestore:
  hash: "$2y$12$DpwmetHKwgYnorbgdvORCenv4NAK8cPUg8AI6pxLCuWf/ALc0.v7W"
  reserved: false
  backend_roles:
  - "snapshotrestore"
  description: "Demo snapshotrestore user, using external role mapping"

admin@linuxser:~/opensearch$ cat roles_mapping.yml
---
# In this file users, backendroles and hosts can be mapped to Security roles.
# Permissions for OpenSearch roles are configured in roles.yml

_meta:
  type: "rolesmapping"
  config_version: 2

# Define your roles mapping here

## Demo roles mapping

all_access:
  reserved: false
  backend_roles:
  - "admin"
  description: "Maps admin to all_access"

own_index:
  reserved: false
  users:
  - "*"
  description: "Allow full access to an index named like the username"

logstash:
  reserved: false
  backend_roles:
  - "logstash"

kibana_user:
  reserved: false
  backend_roles:
  - "kibanauser"
  description: "Maps kibanauser to kibana_user"

readall:
  reserved: false
  backend_roles:
  - "readall"

manage_snapshots:
  reserved: false
  backend_roles:
  - "snapshotrestore"

kibana_server:
  reserved: true
  users:
  - "kibanaserver"

admin@linuxser:~/opensearch$ cat roles.yml
_meta:
  type: "roles"
  config_version: 2

# Restrict users so they can only view visualization and dashboard on OpenSearchDashboards
kibana_read_only:
  reserved: true

# The security REST API access role is used to assign specific users access to change the security settings through the REST API.
security_rest_api_access:
  reserved: true

security_rest_api_full_access:
  reserved: true
  cluster_permissions:
    - 'restapi:admin/actiongroups'
    - 'restapi:admin/allowlist'
    - 'restapi:admin/config/update'
    - 'restapi:admin/internalusers'
    - 'restapi:admin/nodesdn'
    - 'restapi:admin/roles'
    - 'restapi:admin/rolesmapping'
    - 'restapi:admin/ssl/certs/info'
    - 'restapi:admin/ssl/certs/reload'
    - 'restapi:admin/tenants'

# Allows users to view monitors, destinations and alerts
alerting_read_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opendistro/alerting/alerts/get'
    - 'cluster:admin/opendistro/alerting/destination/get'
    - 'cluster:admin/opendistro/alerting/monitor/get'
    - 'cluster:admin/opendistro/alerting/monitor/search'
    - 'cluster:admin/opensearch/alerting/comments/search'
    - 'cluster:admin/opensearch/alerting/findings/get'
    - 'cluster:admin/opensearch/alerting/remote/indexes/get'
    - 'cluster:admin/opensearch/alerting/workflow/get'
    - 'cluster:admin/opensearch/alerting/workflow_alerts/get'

# Allows users to view and acknowledge alerts
alerting_ack_alerts:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opendistro/alerting/alerts/*'
    - 'cluster:admin/opendistro/alerting/chained_alerts/*'
    - 'cluster:admin/opendistro/alerting/workflow_alerts/*'
    - 'cluster:admin/opensearch/alerting/comments/*'

# Allows users to use all alerting functionality
alerting_full_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opendistro/alerting/*'
    - 'cluster:admin/opensearch/alerting/*'
    - 'cluster:admin/opensearch/notifications/feature/publish'
    - 'cluster_monitor'
  index_permissions:
    - index_patterns:
        - '*'
      allowed_actions:
        - 'indices:admin/aliases/get'
        - 'indices:admin/mappings/get'
        - 'indices_monitor'

# Allow users to read Anomaly Detection detectors and results
anomaly_read_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opendistro/ad/detector/info'
    - 'cluster:admin/opendistro/ad/detector/search'
    - 'cluster:admin/opendistro/ad/detector/validate'
    - 'cluster:admin/opendistro/ad/detectors/get'
    - 'cluster:admin/opendistro/ad/result/search'
    - 'cluster:admin/opendistro/ad/result/topAnomalies'
    - 'cluster:admin/opendistro/ad/tasks/search'

# Allows users to use all Anomaly Detection functionality
anomaly_full_access:
  reserved: true
  cluster_permissions:
    - "cluster:admin/ingest/pipeline/delete"
    - "cluster:admin/ingest/pipeline/put"
    - 'cluster:admin/opendistro/ad/*'
    - 'cluster_monitor'
  index_permissions:
    - index_patterns:
        - '*'
      allowed_actions:
        - 'indices:admin/aliases/get'
        - 'indices:admin/mappings/fields/get'
        - 'indices:admin/mappings/fields/get*'
        - 'indices:admin/mappings/get'
        - 'indices:admin/resolve/index'
        - 'indices:admin/setting/put'
        - 'indices:data/read/field_caps*'
        - 'indices:data/read/search'
        - 'indices_monitor'

# Allow users to execute read only k-NN actions
knn_read_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/knn_get_model_action'
    - 'cluster:admin/knn_search_model_action'
    - 'cluster:admin/knn_stats_action'

# Allow users to use all k-NN functionality
knn_full_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/knn_delete_model_action'
    - 'cluster:admin/knn_get_model_action'
    - 'cluster:admin/knn_remove_model_from_cache_action'
    - 'cluster:admin/knn_search_model_action'
    - 'cluster:admin/knn_stats_action'
    - 'cluster:admin/knn_training_job_route_decision_info_action'
    - 'cluster:admin/knn_training_job_router_action'
    - 'cluster:admin/knn_training_model_action'
    - 'cluster:admin/knn_update_model_graveyard_action'
    - 'cluster:admin/knn_warmup_action'

# Allow users to execute read only ip2geo datasource action
ip2geo_datasource_read_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/geospatial/datasource/get'

# Allow users to use all ip2geo datasource action
ip2geo_datasource_full_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/geospatial/datasource/*'

# Allows users to read Notebooks
notebooks_read_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opendistro/notebooks/get'
    - 'cluster:admin/opendistro/notebooks/list'

# Allows users to all Notebooks functionality
notebooks_full_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opendistro/notebooks/create'
    - 'cluster:admin/opendistro/notebooks/delete'
    - 'cluster:admin/opendistro/notebooks/get'
    - 'cluster:admin/opendistro/notebooks/list'
    - 'cluster:admin/opendistro/notebooks/update'

# Allows users to read observability objects
observability_read_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opensearch/observability/get'

# Allows users to all Observability functionality
observability_full_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opensearch/observability/create'
    - 'cluster:admin/opensearch/observability/delete'
    - 'cluster:admin/opensearch/observability/get'
    - 'cluster:admin/opensearch/observability/update'

# Allows users to all PPL functionality
ppl_full_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opensearch/ppl'
  index_permissions:
    - index_patterns:
        - '*'
      allowed_actions:
        - 'indices:admin/mappings/get'
        - 'indices:data/read/search*'
        - 'indices:monitor/settings/get'

# Allows users to read and download Reports
reports_instances_read_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opendistro/reports/instance/get'
    - 'cluster:admin/opendistro/reports/instance/list'
    - 'cluster:admin/opendistro/reports/menu/download'

# Allows users to read and download Reports and Report-definitions
reports_read_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opendistro/reports/definition/get'
    - 'cluster:admin/opendistro/reports/definition/list'
    - 'cluster:admin/opendistro/reports/instance/get'
    - 'cluster:admin/opendistro/reports/instance/list'
    - 'cluster:admin/opendistro/reports/menu/download'

# Allows users to all Reports functionality
reports_full_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opendistro/reports/definition/create'
    - 'cluster:admin/opendistro/reports/definition/delete'
    - 'cluster:admin/opendistro/reports/definition/get'
    - 'cluster:admin/opendistro/reports/definition/list'
    - 'cluster:admin/opendistro/reports/definition/on_demand'
    - 'cluster:admin/opendistro/reports/definition/update'
    - 'cluster:admin/opendistro/reports/instance/get'
    - 'cluster:admin/opendistro/reports/instance/list'
    - 'cluster:admin/opendistro/reports/menu/download'

# Allows users to use all asynchronous-search functionality
asynchronous_search_full_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opendistro/asynchronous_search/*'
  index_permissions:
    - index_patterns:
        - '*'
      allowed_actions:
        - 'indices:data/read/search*'

# Allows users to read stored asynchronous-search results
asynchronous_search_read_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opendistro/asynchronous_search/get'

# Allows user to use all index_management actions - ism policies, rollups, transforms
index_management_full_access:
  reserved: true
  cluster_permissions:
    - "cluster:admin/opendistro/ism/*"
    - "cluster:admin/opendistro/rollup/*"
    - "cluster:admin/opendistro/transform/*"
    - "cluster:admin/opensearch/controlcenter/lron/*"
    - "cluster:admin/opensearch/notifications/channels/get"
    - "cluster:admin/opensearch/notifications/feature/publish"
  index_permissions:
    - index_patterns:
        - '*'
      allowed_actions:
        - 'indices:admin/opensearch/ism/*'
        - 'indices:internal/plugins/replication/index/stop'

# Allows users to use all cross cluster replication functionality at leader cluster
cross_cluster_replication_leader_full_access:
  reserved: true
  index_permissions:
    - index_patterns:
        - '*'
      allowed_actions:
        - "indices:admin/plugins/replication/index/setup/validate"
        - "indices:data/read/plugins/replication/changes"
        - "indices:data/read/plugins/replication/file_chunk"

# Allows users to use all cross cluster replication functionality at follower cluster
cross_cluster_replication_follower_full_access:
  reserved: true
  cluster_permissions:
    - "cluster:admin/plugins/replication/autofollow/update"
  index_permissions:
    - index_patterns:
        - '*'
      allowed_actions:
        - "indices:admin/plugins/replication/index/pause"
        - "indices:admin/plugins/replication/index/resume"
        - "indices:admin/plugins/replication/index/setup/validate"
        - "indices:admin/plugins/replication/index/start"
        - "indices:admin/plugins/replication/index/status_check"
        - "indices:admin/plugins/replication/index/stop"
        - "indices:admin/plugins/replication/index/update"
        - "indices:data/write/plugins/replication/changes"

# Allows users to use all cross cluster search functionality at remote cluster
cross_cluster_search_remote_full_access:
  reserved: true
  index_permissions:
    - index_patterns:
        - '*'
      allowed_actions:
        - 'indices:admin/shards/search_shards'
        - 'indices:data/read/search'

# Allow users to operate query assistant
query_assistant_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opensearch/ml/config/get'
    - 'cluster:admin/opensearch/ml/execute'
    - 'cluster:admin/opensearch/ml/predict'
    - 'cluster:admin/opensearch/ppl'

# Allow users to read ML stats/models/tasks
ml_read_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opensearch/ml/config/get'
    - 'cluster:admin/opensearch/ml/connectors/get'
    - 'cluster:admin/opensearch/ml/connectors/search'
    - 'cluster:admin/opensearch/ml/controllers/get'
    - 'cluster:admin/opensearch/ml/memory/conversation/get'
    - 'cluster:admin/opensearch/ml/memory/conversation/interaction/search'
    - 'cluster:admin/opensearch/ml/memory/conversation/list'
    - 'cluster:admin/opensearch/ml/memory/conversation/search'
    - 'cluster:admin/opensearch/ml/memory/interaction/get'
    - 'cluster:admin/opensearch/ml/memory/interaction/list'
    - 'cluster:admin/opensearch/ml/memory/trace/get'
    - 'cluster:admin/opensearch/ml/model_groups/get'
    - 'cluster:admin/opensearch/ml/model_groups/search'
    - 'cluster:admin/opensearch/ml/models/get'
    - 'cluster:admin/opensearch/ml/models/search'
    - 'cluster:admin/opensearch/ml/profile/nodes'
    - 'cluster:admin/opensearch/ml/stats/nodes'
    - 'cluster:admin/opensearch/ml/tasks/get'
    - 'cluster:admin/opensearch/ml/tasks/search'
    - 'cluster:admin/opensearch/ml/tools/get'
    - 'cluster:admin/opensearch/ml/tools/list'

# Allows users to use all ML functionality
ml_full_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opensearch/ml/*'
    - 'cluster_monitor'
  index_permissions:
    - index_patterns:
        - '*'
      allowed_actions:
        - 'indices_monitor'

# Allows users to use all Notifications functionality
notifications_full_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opensearch/notifications/*'

# Allows users to read Notifications config/channels
notifications_read_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opensearch/notifications/channels/get'
    - 'cluster:admin/opensearch/notifications/configs/get'
    - 'cluster:admin/opensearch/notifications/features'

# Allows users to use all snapshot management functionality
snapshot_management_full_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opensearch/notifications/feature/publish'
    - 'cluster:admin/opensearch/snapshot_management/*'
    - 'cluster:admin/repository/*'
    - 'cluster:admin/snapshot/*'

# Allows users to see snapshots, repositories, and snapshot management policies
snapshot_management_read_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opensearch/snapshot_management/policy/explain'
    - 'cluster:admin/opensearch/snapshot_management/policy/get'
    - 'cluster:admin/opensearch/snapshot_management/policy/search'
    - 'cluster:admin/repository/get'
    - 'cluster:admin/snapshot/get'

# Allows user to use point in time functionality
point_in_time_full_access:
  reserved: true
  index_permissions:
    - index_patterns:
        - '*'
      allowed_actions:
        - 'manage_point_in_time'

# Allows users to see security analytics detectors and others
security_analytics_read_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opensearch/securityanalytics/alerts/get'
    - 'cluster:admin/opensearch/securityanalytics/correlationAlerts/get'
    - 'cluster:admin/opensearch/securityanalytics/correlations/findings'
    - 'cluster:admin/opensearch/securityanalytics/correlations/list'
    - 'cluster:admin/opensearch/securityanalytics/detector/get'
    - 'cluster:admin/opensearch/securityanalytics/detector/search'
    - 'cluster:admin/opensearch/securityanalytics/findings/get'
    - 'cluster:admin/opensearch/securityanalytics/logtype/search'
    - 'cluster:admin/opensearch/securityanalytics/mapping/get'
    - 'cluster:admin/opensearch/securityanalytics/mapping/view/get'
    - 'cluster:admin/opensearch/securityanalytics/rule/get'
    - 'cluster:admin/opensearch/securityanalytics/rule/search'
    - 'cluster:admin/opensearch/securityanalytics/threatintel/alerts/get'
    - 'cluster:admin/opensearch/securityanalytics/threatintel/iocs/findings/get'
    - 'cluster:admin/opensearch/securityanalytics/threatintel/iocs/list'
    - 'cluster:admin/opensearch/securityanalytics/threatintel/monitors/search'
    - 'cluster:admin/opensearch/securityanalytics/threatintel/sources/get'
    -admin@linuxser:~/opensearch$ cat roles.yml
_meta:
  type: "roles"
  config_version: 2

# Restrict users so they can only view visualization and dashboard on OpenSearchDashboards
kibana_read_only:
  reserved: true

# The security REST API access role is used to assign specific users access to change the security settings through the REST API.
security_rest_api_access:
  reserved: true

security_rest_api_full_access:
  reserved: true
  cluster_permissions:
    - 'restapi:admin/actiongroups'
    - 'restapi:admin/allowlist'
    - 'restapi:admin/config/update'
    - 'restapi:admin/internalusers'
    - 'restapi:admin/nodesdn'
    - 'restapi:admin/roles'
    - 'restapi:admin/rolesmapping'
    - 'restapi:admin/ssl/certs/info'
    - 'restapi:admin/ssl/certs/reload'
    - 'restapi:admin/tenants'

# Allows users to view monitors, destinations and alerts
alerting_read_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opendistro/alerting/alerts/get'
    - 'cluster:admin/opendistro/alerting/destination/get'
    - 'cluster:admin/opendistro/alerting/monitor/get'
    - 'cluster:admin/opendistro/alerting/monitor/search'
    - 'cluster:admin/opensearch/alerting/comments/search'
    - 'cluster:admin/opensearch/alerting/findings/get'
    - 'cluster:admin/opensearch/alerting/remote/indexes/get'
    - 'cluster:admin/opensearch/alerting/workflow/get'
    - 'cluster:admin/opensearch/alerting/workflow_alerts/get'

# Allows users to view and acknowledge alerts
alerting_ack_alerts:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opendistro/alerting/alerts/*'
    - 'cluster:admin/opendistro/alerting/chained_alerts/*'
    - 'cluster:admin/opendistro/alerting/workflow_alerts/*'
    - 'cluster:admin/opensearch/alerting/comments/*'

# Allows users to use all alerting functionality
alerting_full_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opendistro/alerting/*'
    - 'cluster:admin/opensearch/alerting/*'
    - 'cluster:admin/opensearch/notifications/feature/publish'
    - 'cluster_monitor'
  index_permissions:
    - index_patterns:
        - '*'
      allowed_actions:
        - 'indices:admin/aliases/get'
        - 'indices:admin/mappings/get'
        - 'indices_monitor'

# Allow users to read Anomaly Detection detectors and results
anomaly_read_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opendistro/ad/detector/info'
    - 'cluster:admin/opendistro/ad/detector/search'
    - 'cluster:admin/opendistro/ad/detector/validate'
    - 'cluster:admin/opendistro/ad/detectors/get'
    - 'cluster:admin/opendistro/ad/result/search'
    - 'cluster:admin/opendistro/ad/result/topAnomalies'
    - 'cluster:admin/opendistro/ad/tasks/search'

# Allows users to use all Anomaly Detection functionality
anomaly_full_access:
  reserved: true
  cluster_permissions:
    - "cluster:admin/ingest/pipeline/delete"
    - "cluster:admin/ingest/pipeline/put"
    - 'cluster:admin/opendistro/ad/*'
    - 'cluster_monitor'
  index_permissions:
    - index_patterns:
        - '*'
      allowed_actions:
        - 'indices:admin/aliases/get'
        - 'indices:admin/mappings/fields/get'
        - 'indices:admin/mappings/fields/get*'
        - 'indices:admin/mappings/get'
        - 'indices:admin/resolve/index'
        - 'indices:admin/setting/put'
        - 'indices:data/read/field_caps*'
        - 'indices:data/read/search'
        - 'indices_monitor'

# Allow users to execute read only k-NN actions
knn_read_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/knn_get_model_action'
    - 'cluster:admin/knn_search_model_action'
    - 'cluster:admin/knn_stats_action'

# Allow users to use all k-NN functionality
knn_full_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/knn_delete_model_action'
    - 'cluster:admin/knn_get_model_action'
    - 'cluster:admin/knn_remove_model_from_cache_action'
    - 'cluster:admin/knn_search_model_action'
    - 'cluster:admin/knn_stats_action'
    - 'cluster:admin/knn_training_job_route_decision_info_action'
    - 'cluster:admin/knn_training_job_router_action'
    - 'cluster:admin/knn_training_model_action'
    - 'cluster:admin/knn_update_model_graveyard_action'
    - 'cluster:admin/knn_warmup_action'

# Allow users to execute read only ip2geo datasource action
ip2geo_datasource_read_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/geospatial/datasource/get'

# Allow users to use all ip2geo datasource action
ip2geo_datasource_full_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/geospatial/datasource/*'

# Allows users to read Notebooks
notebooks_read_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opendistro/notebooks/get'
    - 'cluster:admin/opendistro/notebooks/list'

# Allows users to all Notebooks functionality
notebooks_full_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opendistro/notebooks/create'
    - 'cluster:admin/opendistro/notebooks/delete'
    - 'cluster:admin/opendistro/notebooks/get'
    - 'cluster:admin/opendistro/notebooks/list'
    - 'cluster:admin/opendistro/notebooks/update'

# Allows users to read observability objects
observability_read_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opensearch/observability/get'

# Allows users to all Observability functionality
observability_full_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opensearch/observability/create'
    - 'cluster:admin/opensearch/observability/delete'
    - 'cluster:admin/opensearch/observability/get'
    - 'cluster:admin/opensearch/observability/update'

# Allows users to all PPL functionality
ppl_full_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opensearch/ppl'
  index_permissions:
    - index_patterns:
        - '*'
      allowed_actions:
        - 'indices:admin/mappings/get'
        - 'indices:data/read/search*'
        - 'indices:monitor/settings/get'

# Allows users to read and download Reports
reports_instances_read_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opendistro/reports/instance/get'
    - 'cluster:admin/opendistro/reports/instance/list'
    - 'cluster:admin/opendistro/reports/menu/download'

# Allows users to read and download Reports and Report-definitions
reports_read_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opendistro/reports/definition/get'
    - 'cluster:admin/opendistro/reports/definition/list'
    - 'cluster:admin/opendistro/reports/instance/get'
    - 'cluster:admin/opendistro/reports/instance/list'
    - 'cluster:admin/opendistro/reports/menu/download'

# Allows users to all Reports functionality
reports_full_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opendistro/reports/definition/create'
    - 'cluster:admin/opendistro/reports/definition/delete'
    - 'cluster:admin/opendistro/reports/definition/get'
    - 'cluster:admin/opendistro/reports/definition/list'
    - 'cluster:admin/opendistro/reports/definition/on_demand'
    - 'cluster:admin/opendistro/reports/definition/update'
    - 'cluster:admin/opendistro/reports/instance/get'
    - 'cluster:admin/opendistro/reports/instance/list'
    - 'cluster:admin/opendistro/reports/menu/download'

# Allows users to use all asynchronous-search functionality
asynchronous_search_full_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opendistro/asynchronous_search/*'
  index_permissions:
    - index_patterns:
        - '*'
      allowed_actions:
        - 'indices:data/read/search*'

# Allows users to read stored asynchronous-search results
asynchronous_search_read_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opendistro/asynchronous_search/get'

# Allows user to use all index_management actions - ism policies, rollups, transforms
index_management_full_access:
  reserved: true
  cluster_permissions:
    - "cluster:admin/opendistro/ism/*"
    - "cluster:admin/opendistro/rollup/*"
    - "cluster:admin/opendistro/transform/*"
    - "cluster:admin/opensearch/controlcenter/lron/*"
    - "cluster:admin/opensearch/notifications/channels/get"
    - "cluster:admin/opensearch/notifications/feature/publish"
  index_permissions:
    - index_patterns:
        - '*'
      allowed_actions:
        - 'indices:admin/opensearch/ism/*'
        - 'indices:internal/plugins/replication/index/stop'

# Allows users to use all cross cluster replication functionality at leader cluster
cross_cluster_replication_leader_full_access:
  reserved: true
  index_permissions:
    - index_patterns:
        - '*'
      allowed_actions:
        - "indices:admin/plugins/replication/index/setup/validate"
        - "indices:data/read/plugins/replication/changes"
        - "indices:data/read/plugins/replication/file_chunk"

# Allows users to use all cross cluster replication functionality at follower cluster
cross_cluster_replication_follower_full_access:
  reserved: true
  cluster_permissions:
    - "cluster:admin/plugins/replication/autofollow/update"
  index_permissions:
    - index_patterns:
        - '*'
      allowed_actions:
        - "indices:admin/plugins/replication/index/pause"
        - "indices:admin/plugins/replication/index/resume"
        - "indices:admin/plugins/replication/index/setup/validate"
        - "indices:admin/plugins/replication/index/start"
        - "indices:admin/plugins/replication/index/status_check"
        - "indices:admin/plugins/replication/index/stop"
        - "indices:admin/plugins/replication/index/update"
        - "indices:data/write/plugins/replication/changes"

# Allows users to use all cross cluster search functionality at remote cluster
cross_cluster_search_remote_full_access:
  reserved: true
  index_permissions:
    - index_patterns:
        - '*'
      allowed_actions:
        - 'indices:admin/shards/search_shards'
        - 'indices:data/read/search'

# Allow users to operate query assistant
query_assistant_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opensearch/ml/config/get'
    - 'cluster:admin/opensearch/ml/execute'
    - 'cluster:admin/opensearch/ml/predict'
    - 'cluster:admin/opensearch/ppl'

# Allow users to read ML stats/models/tasks
ml_read_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opensearch/ml/config/get'
    - 'cluster:admin/opensearch/ml/connectors/get'
    - 'cluster:admin/opensearch/ml/connectors/search'
    - 'cluster:admin/opensearch/ml/controllers/get'
    - 'cluster:admin/opensearch/ml/memory/conversation/get'
    - 'cluster:admin/opensearch/ml/memory/conversation/interaction/search'
    - 'cluster:admin/opensearch/ml/memory/conversation/list'
    - 'cluster:admin/opensearch/ml/memory/conversation/search'
    - 'cluster:admin/opensearch/ml/memory/interaction/get'
    - 'cluster:admin/opensearch/ml/memory/interaction/list'
    - 'cluster:admin/opensearch/ml/memory/trace/get'
    - 'cluster:admin/opensearch/ml/model_groups/get'
    - 'cluster:admin/opensearch/ml/model_groups/search'
    - 'cluster:admin/opensearch/ml/models/get'
    - 'cluster:admin/opensearch/ml/models/search'
    - 'cluster:admin/opensearch/ml/profile/nodes'
    - 'cluster:admin/opensearch/ml/stats/nodes'
    - 'cluster:admin/opensearch/ml/tasks/get'
    - 'cluster:admin/opensearch/ml/tasks/search'
    - 'cluster:admin/opensearch/ml/tools/get'
    - 'cluster:admin/opensearch/ml/tools/list'

# Allows users to use all ML functionality
ml_full_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opensearch/ml/*'
    - 'cluster_monitor'
  index_permissions:
    - index_patterns:
        - '*'
      allowed_actions:
        - 'indices_monitor'

# Allows users to use all Notifications functionality
notifications_full_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opensearch/notifications/*'

# Allows users to read Notifications config/channels
notifications_read_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opensearch/notifications/channels/get'
    - 'cluster:admin/opensearch/notifications/configs/get'
    - 'cluster:admin/opensearch/notifications/features'

# Allows users to use all snapshot management functionality
snapshot_management_full_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opensearch/notifications/feature/publish'
    - 'cluster:admin/opensearch/snapshot_management/*'
    - 'cluster:admin/repository/*'
    - 'cluster:admin/snapshot/*'

# Allows users to see snapshots, repositories, and snapshot management policies
snapshot_management_read_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opensearch/snapshot_management/policy/explain'
    - 'cluster:admin/opensearch/snapshot_management/policy/get'
    - 'cluster:admin/opensearch/snapshot_management/policy/search'
    - 'cluster:admin/repository/get'
    - 'cluster:admin/snapshot/get'

# Allows user to use point in time functionality
point_in_time_full_access:
  reserved: true
  index_permissions:
    - index_patterns:
        - '*'
      allowed_actions:
        - 'manage_point_in_time'

# Allows users to see security analytics detectors and others
security_analytics_read_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opensearch/securityanalytics/alerts/get'
    - 'cluster:admin/opensearch/securityanalytics/correlationAlerts/get'
    - 'cluster:admin/opensearch/securityanalytics/correlations/findings'
    - 'cluster:admin/opensearch/securityanalytics/correlations/list'
    - 'cluster:admin/opensearch/securityanalytics/detector/get'
    - 'cluster:admin/opensearch/securityanalytics/detector/search'
    - 'cluster:admin/opensearch/securityanalytics/findings/get'
    - 'cluster:admin/opensearch/securityanalytics/logtype/search'
    - 'cluster:admin/opensearch/securityanalytics/mapping/get'
    - 'cluster:admin/opensearch/securityanalytics/mapping/view/get'
    - 'cluster:admin/opensearch/securityanalytics/rule/get'
    - 'cluster:admin/opensearch/securityanalytics/rule/search'
    - 'cluster:admin/opensearch/securityanalytics/threatintel/alerts/get'
    - 'cluster:admin/opensearch/securityanalytics/threatintel/iocs/findings/get'
    - 'cluster:admin/opensearch/securityanalytics/threatintel/iocs/list'
    - 'cluster:admin/opensearch/securityanalytics/threatintel/monitors/search'
    - 'cluster:admin/opensearch/securityanalytics/threatintel/sources/get'
    - 'cluster:admin/opensearch/securityanalytics/threatintel/sources/search'

# Allows users to use all security analytics functionality
security_analytics_full_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opensearch/securityanalytics/alerts/*'
    - 'cluster:admin/opensearch/securityanalytics/connections/*'
    - 'cluster:admin/opensearch/securityanalytics/correlationAlerts/*'
    - 'cluster:admin/opensearch/securityanalytics/correlations/*'
    - 'cluster:admin/opensearch/securityanalytics/detector/*'
    - 'cluster:admin/opensearch/securityanalytics/findings/*'
    - 'cluster:admin/opensearch/securityanalytics/logtype/*'
    - 'cluster:admin/opensearch/securityanalytics/mapping/*'
    - 'cluster:admin/opensearch/securityanalytics/rule/*'
    - 'cluster:admin/opensearch/securityanalytics/threatintel/*'
  index_permissions:
    - index_patterns:
        - '*'
      allowed_actions:
        - 'indices:admin/mapping/put'
        - 'indices:admin/mappings/get'

# Allows users to view and acknowledge alerts
security_analytics_ack_alerts:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opensearch/securityanalytics/alerts/*'
    - 'cluster:admin/opensearch/securityanalytics/correlationAlerts/*'
    - 'cluster:admin/opensearch/securityanalytics/threatintel/alerts/*'

# Allows users to use all Flow Framework functionality
flow_framework_full_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opensearch/flow_framework/*'
    - 'cluster_monitor'
  index_permissions:
    - index_patterns:
        - '*'
      allowed_actions:
        - 'indices:admin/aliases/get'
        - 'indices:admin/mappings/get'
        - 'indices_monitor'

# Allow users to read flow framework's workflows and their state
flow_framework_read_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opensearch/flow_framework/workflow/get'
    - 'cluster:admin/opensearch/flow_framework/workflow/search'
    - 'cluster:admin/opensearch/flow_framework/workflow_state/get'
    - 'cluster:admin/opensearch/flow_framework/workflow_state/search'
    - 'cluster:admin/opensearch/flow_framework/workflow_step/get'

# Allows users to use all query insights APIs
query_insights_full_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opensearch/insights/*'
  index_permissions:
    - index_patterns:
        - 'top_queries-*'
      allowed_actions:
        - "indices_all"

# Allow users to execute read only LTR actions
ltr_read_access:
  reserved: true
  cluster_permissions:
    - cluster:admin/ltr/caches/stats
    - cluster:admin/ltr/featurestore/list
    - cluster:admin/ltr/stats

# Allow users to execute all LTR actions
ltr_full_access:
  reserved: true
  cluster_permissions:
    - cluster:admin/ltr/*

# Allow users to use all Search Relevance functionalities
search_relevance_full_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opensearch/search_relevance/*'
  index_permissions:
    - index_patterns:
        - '*'
      allowed_actions:
        - 'indices:admin/mappings/get'
        - 'indices:data/read/search*'

# Allow users to read Search Relevance resources
search_relevance_read_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opensearch/search_relevance/experiment/get'
    - 'cluster:admin/opensearch/search_relevance/judgment/get'
    - 'cluster:admin/opensearch/search_relevance/queryset/get'
    - 'cluster:admin/opensearch/search_relevance/search_configuration/get'

# Allow users to read Forecast resources
forecast_read_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/plugin/forecast/forecaster/info'
    - 'cluster:admin/plugin/forecast/forecaster/stats'
    - 'cluster:admin/plugin/forecast/forecaster/suggest'
    - 'cluster:admin/plugin/forecast/forecaster/validate'
    - 'cluster:admin/plugin/forecast/forecasters/get'
    - 'cluster:admin/plugin/forecast/forecasters/info'
    - 'cluster:admin/plugin/forecast/forecasters/search'
    - 'cluster:admin/plugin/forecast/result/topForecasts'
    - 'cluster:admin/plugin/forecast/tasks/search'
  index_permissions:
    - index_patterns:
        - 'opensearch-forecast-result*'
      allowed_actions:
        - 'indices:admin/mappings/fields/get*'
        - 'indices:admin/resolve/index'
        - 'indices:data/read*'

# Allows users to use all Forecasting functionality
forecast_full_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/plugin/forecast/*'
    - 'cluster:admin/settings/update'
    - 'cluster_monitor'
  index_permissions:
    - index_patterns:
        - '*'
      allowed_actions:
        - 'indices:admin/aliases/get'
        - 'indices:admin/mapping/get'
        - 'indices:admin/mapping/put'
        - 'indices:admin/mappings/fields/get*'
        - 'indices:admin/mappings/get'
        - 'indices:admin/resolve/index'
        - 'indices:data/read*'
        - 'indices:data/read/field_caps*'
        - 'indices:data/read/search'
        - 'indices:data/write*'
        - 'indices_monitor' 'cluster:admin/opensearch/securityanalytics/threatintel/sources/search'

# Allows users to use all security analytics functionality
security_analytics_full_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opensearch/securityanalytics/alerts/*'
    - 'cluster:admin/opensearch/securityanalytics/connections/*'
    - 'cluster:admin/opensearch/securityanalytics/correlationAlerts/*'
    - 'cluster:admin/opensearch/securityanalytics/correlations/*'
    - 'cluster:admin/opensearch/securityanalytics/detector/*'
    - 'cluster:admin/opensearch/securityanalytics/findings/*'
    - 'cluster:admin/opensearch/securityanalytics/logtype/*'
    - 'cluster:admin/opensearch/securityanalytics/mapping/*'
    - 'cluster:admin/opensearch/securityanalytics/rule/*'
    - 'cluster:admin/opensearch/securityanalytics/threatintel/*'
  index_permissions:
    - index_patterns:
        - '*'
      allowed_actions:
        - 'indices:admin/mapping/put'
        - 'indices:admin/mappings/get'

# Allows users to view and acknowledge alerts
security_analytics_ack_alerts:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opensearch/securityanalytics/alerts/*'
    - 'cluster:admin/opensearch/securityanalytics/correlationAlerts/*'
    - 'cluster:admin/opensearch/securityanalytics/threatintel/alerts/*'

# Allows users to use all Flow Framework functionality
flow_framework_full_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opensearch/flow_framework/*'
    - 'cluster_monitor'
  index_permissions:
    - index_patterns:
        - '*'
      allowed_actions:
        - 'indices:admin/aliases/get'
        - 'indices:admin/mappings/get'
        - 'indices_monitor'

# Allow users to read flow framework's workflows and their state
flow_framework_read_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opensearch/flow_framework/workflow/get'
    - 'cluster:admin/opensearch/flow_framework/workflow/search'
    - 'cluster:admin/opensearch/flow_framework/workflow_state/get'
    - 'cluster:admin/opensearch/flow_framework/workflow_state/search'
    - 'cluster:admin/opensearch/flow_framework/workflow_step/get'

# Allows users to use all query insights APIs
query_insights_full_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opensearch/insights/*'
  index_permissions:
    - index_patterns:
        - 'top_queries-*'
      allowed_actions:
        - "indices_all"

# Allow users to execute read only LTR actions
ltr_read_access:
  reserved: true
  cluster_permissions:
    - cluster:admin/ltr/caches/stats
    - cluster:admin/ltr/featurestore/list
    - cluster:admin/ltr/stats

# Allow users to execute all LTR actions
ltr_full_access:
  reserved: true
  cluster_permissions:
    - cluster:admin/ltr/*

# Allow users to use all Search Relevance functionalities
search_relevance_full_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opensearch/search_relevance/*'
  index_permissions:
    - index_patterns:
        - '*'
      allowed_actions:
        - 'indices:admin/mappings/get'
        - 'indices:data/read/search*'

# Allow users to read Search Relevance resources
search_relevance_read_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/opensearch/search_relevance/experiment/get'
    - 'cluster:admin/opensearch/search_relevance/judgment/get'
    - 'cluster:admin/opensearch/search_relevance/queryset/get'
    - 'cluster:admin/opensearch/search_relevance/search_configuration/get'

# Allow users to read Forecast resources
forecast_read_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/plugin/forecast/forecaster/info'
    - 'cluster:admin/plugin/forecast/forecaster/stats'
    - 'cluster:admin/plugin/forecast/forecaster/suggest'
    - 'cluster:admin/plugin/forecast/forecaster/validate'
    - 'cluster:admin/plugin/forecast/forecasters/get'
    - 'cluster:admin/plugin/forecast/forecasters/info'
    - 'cluster:admin/plugin/forecast/forecasters/search'
    - 'cluster:admin/plugin/forecast/result/topForecasts'
    - 'cluster:admin/plugin/forecast/tasks/search'
  index_permissions:
    - index_patterns:
        - 'opensearch-forecast-result*'
      allowed_actions:
        - 'indices:admin/mappings/fields/get*'
        - 'indices:admin/resolve/index'
        - 'indices:data/read*'

# Allows users to use all Forecasting functionality
forecast_full_access:
  reserved: true
  cluster_permissions:
    - 'cluster:admin/plugin/forecast/*'
    - 'cluster:admin/settings/update'
    - 'cluster_monitor'
  index_permissions:
    - index_patterns:
        - '*'
      allowed_actions:
        - 'indices:admin/aliases/get'
        - 'indices:admin/mapping/get'
        - 'indices:admin/mapping/put'
        - 'indices:admin/mappings/fields/get*'
        - 'indices:admin/mappings/get'
        - 'indices:admin/resolve/index'
        - 'indices:data/read*'
        - 'indices:data/read/field_caps*'
        - 'indices:data/read/search'
        - 'indices:data/write*'
        - 'indices_monitor'

admin@linuxser:~/opensearch$ cat audit.yml
_meta:
type: "audit"
config_version: 2

config:
# enable/disable audit logging
enabled: true

audit:
# Enable/disable REST API auditing
enable_rest: true

# Categories to exclude from REST API auditing
disabled_rest_categories:
- AUTHENTICATED
- GRANTED_PRIVILEGES

# Enable/disable Transport API auditing
enable_transport: true

# Categories to exclude from Transport API auditing
disabled_transport_categories:
- AUTHENTICATED
- GRANTED_PRIVILEGES

# Users to be excluded from auditing. Wildcard patterns are supported. Eg:
# ignore_users: ["test-user", "employee-*"]
ignore_users:
- kibanaserver

# Requests to be excluded from auditing. Wildcard patterns are supported. Eg:
# ignore_requests: ["indices:data/read/*", "SearchRequest"]
ignore_requests: []

# Log individual operations in a bulk request
resolve_bulk_requests: false

# Include the body of the request (if available) for both REST and the transport layer
log_request_body: true

# Logs all indices affected by a request. Resolves aliases and wildcards/date patterns
resolve_indices: true

# Exclude sensitive headers from being included in the logs. Eg: Authorization
exclude_sensitive_headers: true

compliance:
# enable/disable compliance
enabled: true

# Log updates to internal security changes
internal_config: true

# Log external config files for the node
external_config: false

# Log only metadata of the document for read events
read_metadata_only: true

# Map of indexes and fields to monitor for read events. Wildcard patterns are supported for both index names and fields. Eg:
# read_watched_fields: {
# "twitter": ["message"]
# "logs-*": ["id", "attr*"]
# }
read_watched_fields: {}

# List of users to ignore for read events. Wildcard patterns are supported. Eg:
# read_ignore_users: ["test-user", "employee-*"]
read_ignore_users:
- kibanaserver

# Log only metadata of the document for write events
write_metadata_only: true

# Log only diffs for document updates
write_log_diffs: false

# List of indices to watch for write events. Wildcard patterns are supported
# write_watched_indices: ["twitter", "logs-*"]
write_watched_indices: []

# List of users to ignore for write events. Wildcard patterns are supported. Eg:
# write_ignore_users: ["test-user", "employee-*"]
write_ignore_users:
- kibanaserver

Step6: Prepare Docker Compose file

Let’s now prepare our docker compose file with our TLS certificates and the security related configuration files volume mounted into the each container as shown below.

Ensure that you have the OpenSearch “admin” user password initialized in the environment file before starting up the OpenSearch cluster.

admin@linuxser:~/opensearch$ cat .env
OPENSEARCH_INITIAL_ADMIN_PASSWORD=Se@rch@2025

admin@linuxser:~/opensearch$ cat docker-compose.yml
services:
  opensearch-node1:
    image: opensearchproject/opensearch:3.3.0
    container_name: opensearch-node1
    environment:
      - cluster.name=opensearch-cluster
      - node.name=opensearch-node1
      - discovery.seed_hosts=opensearch-node1,opensearch-node2
      - cluster.initial_master_nodes=opensearch-node1,opensearch-node2
      - bootstrap.memory_lock=true
      - "OPENSEARCH_JAVA_OPTS=-Xms2g -Xmx2g"
    ulimits:
      memlock:
        soft: -1
        hard: -1
      nofile:
        soft: 65536
        hard: 65536
    volumes:
      - ./opensearch.yml:/usr/share/opensearch/config/opensearch.yml
      - ./esnode.pem:/usr/share/opensearch/config/esnode.pem
      - ./esnode-key.pem:/usr/share/opensearch/config/esnode-key.pem
      - ./root-ca.pem:/usr/share/opensearch/config/root-ca.pem
      - ./kirk-key.pem:/usr/share/opensearch/config/kirk-key.pem
      - ./kirk.pem:/usr/share/opensearch/config/kirk.pem
      - ./config.yml:/usr/share/opensearch/config/opensearch-security/config.yml
      - ./roles_mapping.yml:/usr/share/opensearch/config/opensearch-security/roles_mapping.yml
      - ./roles.yml:/usr/share/opensearch/config/opensearch-security/roles.yml
      - ./audit.yml:/usr/share/opensearch/config/opensearch-security/audit.yml
      - ./internal_users.yml:/usr/share/opensearch/config/opensearch-security/internal_users.yml
    ports:
      - 9201:9200
      - 9600:9600
    networks:
      - opensearch-net

  opensearch-node2:
    image: opensearchproject/opensearch:3.3.0
    container_name: opensearch-node2
    environment:
      - cluster.name=opensearch-cluster
      - node.name=opensearch-node2
      - discovery.seed_hosts=opensearch-node1,opensearch-node2
      - cluster.initial_master_nodes=opensearch-node1,opensearch-node2
      - bootstrap.memory_lock=true
      - "OPENSEARCH_JAVA_OPTS=-Xms2g -Xmx2g"
    ulimits:
      memlock:
        soft: -1
        hard: -1
      nofile:
        soft: 65536
        hard: 65536
    volumes:
      - ./opensearch.yml:/usr/share/opensearch/config/opensearch.yml
      - ./esnode.pem:/usr/share/opensearch/config/esnode.pem
      - ./esnode-key.pem:/usr/share/opensearch/config/esnode-key.pem
      - ./root-ca.pem:/usr/share/opensearch/config/root-ca.pem
      - ./kirk-key.pem:/usr/share/opensearch/config/kirk-key.pem
      - ./kirk.pem:/usr/share/opensearch/config/kirk.pem
      - ./config.yml:/usr/share/opensearch/config/opensearch-security/config.yml
      - ./roles_mapping.yml:/usr/share/opensearch/config/opensearch-security/roles_mapping.yml
      - ./roles.yml:/usr/share/opensearch/config/opensearch-security/roles.yml
      - ./audit.yml:/usr/share/opensearch/config/opensearch-security/audit.yml
      - ./internal_users.yml:/usr/share/opensearch/config/opensearch-security/internal_users.yml
    ports:
      - 9200:9200
    networks:
      - opensearch-net

  opensearch-dashboards:
    image: opensearchproject/opensearch-dashboards:3.3.0
    container_name: opensearch-dashboards
    volumes:
      - ./opensearch_dashboards.yml:/usr/share/opensearch-dashboards/config/opensearch_dashboards.yml
      - ./opensearch_dashboards.crt:/usr/share/opensearch-dashboards/config/opensearch_dashboards.crt
      - ./opensearch_dashboards.key:/usr/share/opensearch-dashboards/config/opensearch_dashboards.key
    ports:
      - 5601:5601
    expose:
      - "5601"
    environment:
      OPENSEARCH_HOSTS: '["https://opensearch-node1:9200", "https://opensearch-node2:9200", "https://opensearch-node3:9200" ]'
    networks:
      - opensearch-net
    depends_on:
      - opensearch-node1
      - opensearch-node2

networks:
  opensearch-net:

Step7: Start OpenSearch services

It’s time to startup our OpenSearch and OpenSearch dashboard services as shown below.

admin@linuxser:~/opensearch$ docker compose up -d

Step8: Validate OpenSearch Cluster

Once the OpenSearch cluster services are up and running we can verify the cluster status.

### Get cluster status
GET https://linuxser.stack.com:9200/_cluster/health
Authorization: Basic admin:Se@rch@2025
Accept: application/json
Content-Type: application/json

Now, let’s verify the OpenSearch Node certificate.

admin@fedser:blogs$ openssl s_client -connect linuxser.stack.com:9200
...
---
Certificate chain
 0 s:C = IN, ST = MH, L = Mumbai, O = stack, OU = middleware, CN = opensearch-node.stack.com
   i:C = IN, ST = MH, L = Mumbai, O = stack, OU = middleware, CN = linuxser.stack.com
   a:PKEY: rsaEncryption, 2048 (bit); sigalg: RSA-SHA256
   v:NotBefore: Oct 25 18:25:29 2025 GMT; NotAfter: Oct 25 18:25:29 2027 GMT
---

Also let’s verify the OpenSearch Dashboard certificate.

admin@fedser:blogs$ openssl s_client -connect linuxser.stack.com:5601
...
---
Certificate chain
 0 s:C = IN, ST = MH, L = Mumbai, O = stack, OU = middleware, CN = linuxser.stack.com
   i:C = IN, ST = MH, L = Mumbai, O = stack, OU = middleware, CN = linuxser.stack.com
   a:PKEY: rsaEncryption, 2048 (bit); sigalg: RSA-SHA256
   v:NotBefore: Oct 25 18:25:29 2025 GMT; NotAfter: Oct 25 18:25:29 2026 GMT
---

Hope you enjoyed reading this article. Thank you..

How to secure OpenSearch cluster using TLS certificates
